Quick Details

  • Products Status: Stock
  • Type: Wired
  • Application: Mid-range Service Routers
  • Function: Firewall, QoS, VPN
  • LAN Ports: 4
  • WAN Ports: 2
  • Certification: ccc,ce
  • Brand Name: Huawei, Huawei
  • Model Number: NE08E-S6
  • Place of Origin: Guangdong, China (Mainland)
  • Product name: NE08E-S6
  • Warranty: 1 Year
  • Switching Capacity: 112 Gbit/s
  • Forwarding Performance: NED2CXPB: 37.162 Mpps
  • Interfaces: 10 GE/GE/FE, Smart E1/T1, Channelize STM-1, GPON, XDSL,
  • Number of Slots: 2 MPUs DC/External AC 6 FICs Internal AC 4 FICs
  • Power Consumption: 131W
  • Dimensions (H x W x D): 88.9 mm x 442 mm x 220 mm (2U)
  • Operating Temperature: -40°C to 65°C

Packaging & Delivery

Packaging Details Original Carton Package
Delivery Time 3-7 working days after payment

New Huawei NE08E Series Mid-range NE08E-S6 VPN Router

Product Description

NE05E/08E Series Mid-range Service Routers

Compact, mid-range routers with SDN technology, optimized for resilient L2 networking and cloud services. Built with Huawei’s next-generation Ethernet Network Processor (ENP), large cache, support for IP hard pipes and soft pipes, and simplified O&M.

Provision new services without replacing equipment using microcode programming. Separate data and control planes support virtualization options and provide flexibility for central, unified management at access or aggregation layers.

Energy-efficient, plug-and-play design provides flexible networking options and reliable operation in a range of temperatures from -40ºF to 150ºF (-40ºC to 65ºC).









Features



Compact aggregation and PE routers for cloud computing and agile, Software-Defined Networking for the enterprise



•Bi-directional Forwarding Detection (BFD) and Virtual Router Redundancy Protocol (VRRP) allow redundant configurations with fast switchover when services are disrupted
•Large buffers, fast error detection and recovery, and use of IP hard pipes technology ensure smooth service experience
•Plug-and-play and rapid fault detection simplify deployment and maintenance; virtualization simplifies expansion and management
•Visual interfaces enable one-click service provisioning, real-time service quality and performance monitoring, and custom service reports
•SDN architecture, VRP software, and Huawei’s proprietary ENP chips provide agile networking for quickly adapting to new services and user requirements



Smart
IP pipeline firmness and flexibility: supports IP soft pipes for statistical multiplexing to improve resource efficiency and IP hard pipes for resources exclusive. IP hard pipe technology is another major innovation of Huawei in the IP field, on the
basis of the existing network using MPLS-TE, HQoS technology, hardware resources earmarked , to achieve dedicated bandwidth for leased line services, while ensuring low traffic latency, high reliability.
NE08E / NE05E series supports innovative IP hard pipe technology, providing high-quality IP leased line solutions.through hardware strict isolation to ensure that bandwidth of hard pipe is not to be seize, to achieve rigid pipe similar to SDH, while usingdetection technology to achieve flow level service quality perceived, through the network and uTraffic provides graphical display, real-time monitoring of business operating conditions, IP line service can be controllable , manageable and visible.

Hardware NQA & OAM: OAM packets are forwarded by the hardware (CPU does not need to participate in treatment), packet interval of 3.3ms (rather than 10ms), to ensure that the massive services 50ms fast switching, hardware NQA achieve high-precision service quality monitoring; support RFC 2544 / Y.1564, fast implementation failures delimitation and provide performance reports.

Simplified
Plug and play, replace and play, high efficiency deployment : One time site visit and remote plug and play configuration can realize fast provisioning from traditional 30 minutes to 5 minutes;
Access Virtualization: through SDN technology, the routing control plane of NE08E /NE05E can be moved to the aggregation layer router for unified management , the NE08E /NE05E device can be virtualized as aggregation layer remote boards to achieve centralized control, and all network operations for edge routers can concentrate on the aggregation
routers, so as to simplify the network, improve operation and maintenance efficiency.
SDH like, Visualization U2000 NMS, Across IP large network O & M gap: Supporting template and GUI based configuration, hardware-based NQA and fast failure detection mechanisms, which can realize rapid fault location and greatly simplify the IP network operation and maintenance, helping operators across the operation and maintenance gap
from SDH to IP.

Scalable
Self-developed chips, service demand and dynamic: Built-in Huawei self-study network processor ENP chips, with its flexible fully programmable architecture, new services can be achieved by microcode programming, customers do not need to replace the new hardware, saving equipment investment cost; while significantly shortening the service innovation cycle, to help customers implement new services quickly on-line, help customers build resilient and scalable networks.
Covering the whole scene: covering the last mile of variety of scenarios, to meet the coverage of one-stop integrated services.



Any media access Types: GE/FE, E1, STM-1, xDSL, GPON Access ;



Any service bearer solutions portfolio: MS PW, L3VPN to edge, Native IP, MPLS-TP and so on;
Any environment installation: Support AC/DC power, support POE, can be mounted in the cabinet, on the wall, pole and desktop, rain and dust protection design, covering indoor and outdoor installation environment;



Comprehensive clock synchronization solution: Support IEEE1588v2 OC, BC and TC all mode, 1588 ACR, Synchronous Ethernet, Adaptive clock recovery. Fulfill the clock synchronization requirement of evolution in long run and reduce investment on GPS and BITS;

Sustainable
leading industrial design, green concept: low power, green energy, low carbon and environmental protection. Since ENP chips, each GE consumes less than 30% of the industry, 10000 NE reduce 9,970 tons CO2 emissions annually.





Specification





 Attribute

NE08E-S6

NE05E-S2

NE05E-SE/SF

NE05E-SG/SH/SI

NE05E-SJ/SK/SL/SM

Forwarding Capacity

(IPv4/IPv6)

120 Mpps

45 Mpps

66 Mpps

18 Mpps

SJ/SK/SL: 9 Mpps

SM: 6 Mpps

Forwarding Capability (IMIX)

160 Gbit/s

 60 Gbit/s

88 Gbit/s

24 Gbit/s

SJ/SK/SL: 12 Gbit/s

SM: 8 Gbit/s

Interfaces

10 GE/GE/FE, Smart E1/T1, Channelize STM-1, GPON, XDSL, RS232, RS485, FXO, FSO, E&M, X.21/V.35/X.24, etc.

SE: 2 x 10 GE + 16 GE(O) + 8 GE(E)

SF: 2 x 10 GE + 8 GE(O) + 8 GE(E) + 2 x 8 E1



SG: 4 GE(O) + 4 GE(E) + 4 GE Combo

SH: 4 GE(O) + 4 GE(E) + 4 GE Combo + 2 x 8 E1

SI: 4 GE(O) + 4 GE/FE(O) + 4 GE(E)

SJ/SK/SL: 2 x FE/GE(O) + 2 x FE/GE(E) + 2 x FE/GE Combo

Support GPON ONU

SM: 1 x GE(O) + 2 x GE/FE(E) + 1 x FE/GE Combo

Clock

1588v2, ACR, E1 line clock, and sync clock

Power COM

131W

35W

SE:49.8W

SF:52.1W

35W

9.9W

Voltage

-38.4V to -72.0V DC

90V to 280V AC

-38.4V to-72.0V DC

100V to 240V AC

-38.4V to -72.0V DC

100V to 240V AC

-38.4V to -72.0V DC

100V to 240V AC

SJ/SL/SM: 90V  to 260V AC

SK: -38.4V to -72.0V DC

Slots

2 MPUs

6 FICs

1 MPU

2 FICs

0

0

0

Dimensions (H x W x D)

88.9 mm x 442 mm x 220 mm (2U)

44.45 mm x 442 mm x 220 mm (1U)

44.45 mm x 442 mm x 220 mm (1U)

 44 mm x 250 mm x 180 mm

Weight

8.42 kg

4.8 kg

3 kg

3 kg

SJ/SK: 1.81 kg

SK/SL: 2.7 kg

Operating temperature

-40°C to +65°C

-40°C to +65°C

-40°C to +65°C

-40°C to +65°C

SJ/SK/SL: -40°C to +65°C

SM: -40°C to +55°C

Humidity

5% RH to 95% RH, non-condensing
